Information Update
Hardware Owner’s Manual Update
The following tables provide the latest supported memory configurations and
supersedes the information listed in Table 3-2 and Table 3-3 of the Hardware
Owner’s Manual at support.dell.com/manuals.
Table 1. Memory Configurations (Same DIMM Size)
NOTE: DIMMs A1-A8 are assigned to processor 1, DIMMs B1-B8 are assigned to
processor 2, and so on. For configurations with two processors, DIMMs A1-A8 and
DIMMs C1-C8 are assigned to processor 1 while DIMMs B1-B8 and DIMMs D1-D8 are
assigned to processor 2.
Number of Processors
System Capacity (in GB)
DIMM Size (in GB)
Number of DIMMs
Sparing
Mirroring
Processors
CPU1 CPU2 CPU3 CPU4
1 4 1 4 A1,A2 - C1,C2 -
1 16 2 8 A1,A3,
A2,A4
- C1,C3,
C2,C4
-
1 32 2 16 A1,A2,
A3,A4,
A5,A6,
A7,A8
- C1,C2,
C3,C4,
C5,C6,
C7,C8
-
1 64 4 16 A1,A2,
A3,A4,
A5,A6,
A7,A8
- C1,C2,
C3,C4,
C5,C6,
C7,C8
-
July 2010
