EAW LA400 Specifications - Page 1
1
EAW LA400 Specifications - Page 2
2
Acoustic Performance Partnership Eastern Acoustic Works LA400
One Main Street, Whitinsville MA, 01588 USA • Phone 508/234-6158 • Toll Free 800/992-5013 • Fax 508/234-8251 • Web http://www.eaw.com • email [email protected].com
SPECIFICATIONS LA400
A
C
O
U
S
T
I
C
A
L
P
E
R
F
O
R
M
A
N
C
E
P
A
R
T
N
E
R
S
H
I
P
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email [email protected] • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# LA400-888068 (A)/2 pp/4/15/99 • Printed In USA
DESCRIPTION
The LA400 single 12-in bass horn – known as the SuperSub,
Jr.™ – contains bass horn technology that was developed for
the KF940/BH822e SuperSub dual 12-in bass horn which is
setting a new standard for large-scale sub bass performance.
It loads a powerful woofer on a bent bass horn to provide
very high output sub bass response in a compact, portable
enclosure.
The efficiency provided by EAW’s advanced horn-loading
techniques permits the LA400 to extend overall system
frequency to the lowest octaves. Critical listeners will be
rewarded with tight, punchy sub bass response without the
sloppy sound associated with inferior products.
APPLICATIONS
The LA400 is engineered to work as a companion to the
LA460 Virtual Array Technology full range system, as well as
other high-output compact loudspeaker systems. In
addition to complementing the LA460 to achieve optimum
extended range coverage, the LA400 shares common
dimensions and provides an ideal ground stacking platform
for the LA460, raising it to an appropriate height to project
HF information into an audience area.
The “towel bar” handle across the mouth of the horn and
cut-away lower rear corner allows users to roll the LA400
onto its rear-mounted casters with a minimum of effort.
Mounting the casters on the enclosure’s rear lowers the
system’s center of gravity during transport for easier rolling
and more stable packing. A stout grill protects the drivers
from objects that might fall into the horn when on its back.
Applications include:
Band PA Nightclubs
Portable A/V Portable DJ’s
PERFORMANCE
Frequency Response (1 W @ 1m)
±3 dB 45 Hz to 250 Hz
-10 dB 40 Hz
Axial Sensitivity (dB SPL, 1 Watt @ 1m)
Sub Bass 107
Impedance (Ohms)
Sub Bass 8
Power Handling, AES Standard (Watts)
Sub Bass 500
Calculated Maximum Output (dB SPL)
Sub Bass Peak 140.0
Sub Bass Long Term 134.0
Nominal Coverage Angle/-6 dB points (degrees)
Horizontal 180
Vertical 180
Recommended High-Pass Frequency
24 dB/Octave 32
PHYSICAL
Configuration Dedicated subwoofer horn
Sub Bass Subsystem 12-in woofer, bent bass horn
Cabinet Type (shape) Rectangular
Enclosure Materials Baltic birch plywood
Finish Black polyurethane
Connectors 2x Neutrik NL4 Speakon
Grille Powder coated perforated steel
Dimensions inches millimeters
Height 36 914
Width 21 533
Depth 36 914
Weights pounds kilograms
Net Weight 125 56.9
Shipping Weight 133 60.5
Companion Systems
Full Range LA460, LA215, LA325
Processor MX300i
