Roland FP-7F Brochure & specs - Page 1
1
Roland FP-7F Brochure & specs - Page 2
2
Committed to producing products that are inviting to use and easy on the environment
Roland’s Miyakoda Factory in Hamamatsu, Japan, is a state-of-the-art facility that has acquired internationally recognized ISO14001 certification
for its environmental management systems and ISO9001* for quality assurance. Recycled plastic is used for Ivory Feel keyboards and keyboard
parts with no lead materials used in the pianos. Using Roland’s original digital-cell production method, each instrument is individually made by
hand and carefully assembled with low-environmental impact.
*ISO14001 is an international standard for environmental management systems issued by the International Organization for Standardization (ISO). Similarly, ISO9001 is an
international ISO standard for quality management systems. The International Organization for Standardization is a non-government organization that issues internationally
recognized industrial standards, quality control standards, and other standards.
Visit us online at www.Roland.com
Roland,
, SuperNATURAL and V-Piano are either registered trademarks or
trademarks of Roland Corporation in the United States and/or other countries.
All specifications and appearances are subject to change without notice.
All trademarks used in this catalog are the property of their respective companies.
Printed in Japan Feb. 2011 RAM-4682 GR-UPR-SS AIDG1
FP-7F/FP-4F Options
FP-7F/FP-4F Specications
USB Flash Memory
M-UF2G
USB CD Drive
CD-01A
Dedicated Stand
KSC-44-BK / KSC-44-WH
Keyboard Stand
KS-18Z
Pedal Unit
RPU-3
Damper Pedal
DP-10
Expression Pedal
EV-5
Dynamic Microphone
DR-50
(for FP-7F)
Keyboard
Keyboard
88 keys [FP-7F] Ivory Feel-S Keyboard with Escapement [FP-4F] Ivory Feel-G Keyboard with Escapement
Touch Sensitivity
[FP-7F] 100 levels/Fixed Touch, Hammer Response (Off, 1 – 10) [FP-4F ] 5 levels, Fixed Touch
Keyboard Mode
Whole, Dual (volume balance adjustable), Split (split point adjustable)
Sound Generator (Conforms to GM2 / GS / XGlite)
Piano Sound
SuperNATURAL Piano Sound
Piano Effects
Damper Resonance (Off, 1 – 10), String Resonance (Off, 1 – 10), Key Off Resonance (Off, 1 – 10)
[FP-7F o nly] Open/Close Lid (0 – 6), Cabinet Resonance (Off, 1 – 10), Hammer Noise (-2 – 2),
Duplex Scale (Off, 1 – 10), Damper Noise (Off, 1 – 10)
Max. Polyphony
128 voices
Tone
[FP-7F] 351 tones (including 8 drum sets, 1 SFX set) [FP-4F] 345 tones (including 8 drum sets, 1 SFX set)
Temperaments
8 types, selectable temperament key
Stretched Tuning
Off, Preset [FP-7F onl y ] User tuning (adjustable in individual notes: -50.0 – +50.0 cent)
Master Tuning
415.3 Hz – 466.2 Hz (adjustable in increments of 0.1 Hz)
Transpose
-6 – +5 (in semitones)
Effects
Reverb (Off, 1 – 10), Only for Organ Tones: Rotary Speaker Effect (Slow, Fast)
[FP-7F o nly] Only for MIC INPUT: Harmony (Off, 3 types), Reverb (Off, 1 – 10)
Equalizer
4-band Digital Equalizer
Metronome
Tempo
Quarter Note = 10 – 500
Beat
2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8
Recorder
Song
1 Song
Note Storage
Approx. 30,000 notes
Tempo
Quarter Note = 10 – 500
Resolution
120 ticks per quarter note
Playable Song Format
Standard MIDI Files (Format 0/1), Roland Original Format (i-Format)
Transpose
-6 – +5 (in semitones)
Session Partner
Rhythms
80 types x 2 variations
Chord Progression
Automatic or input with keyboard (User Programmable)
Audio
Playable Song Format
Audio File (WAV 44.1 kHz / 16-bit Linear Format), Audio CDs (CD-DA) (when using an optional CD drive)
Audio Playback
Center Cancel, Audio Playback Speed (75 – 125 %), Playback Transpose (-6 – +5, in semitones)
Internal Memory
Songs
Max. 99 songs
Song Save Format
Standard MIDI Files (Format 0)
External Memory
External Storage
USB Flash Memory (sold separately)
Songs
[FP-7F] Max. 999 songs [FP-4F] Max. 99 songs
Song Save Format
Standard MIDI Files (Format 0)
Other
Internal Songs
[FP-7F] 74 songs [FP-4F] 73 songs
Display
[FP-7F] Graphic LCD 128 x 64 dots (with backlit) [FP-4F] Custom LCD (with backlit)
Registrations
[FP-7F] To Internatl Memory: 30 x 25 sets (max.), To External Memory: 30 x 99 sets (max.)
[FP-4F] To Internatl Memory: 20 x 25 sets (max.), To External Memory: 20 x 99 sets (max.)
Other Functions
V-LINK, Tone Demo, Panel Lock [FP-7F only ] Looper, Audio Key, Piano Designer
Connectors
External Memory connector, USB (MIDI) connector, PEDAL jacks (DAMPER/R, SOFT/L (FC1)*,
SOSTENUTO/C (FC2)*): 1/4-inch phone type (*Assignable),
OUTPUT jacks (L/MONO, R): 1/4-inch phone type ,
INPUT jacks (L/MONO, R): 1/4-inch phone type (FP-7F) / RCA phono type (FP-4F),
PHONES jack x 2: Stereo 1/4-inch phone type, MIDI connectors (IN, OUT), DC IN jack,
[FP-7F] MIX IN jack: Stereo miniature phone type, MIC INPUT jack: 1/4-inch phone type
Rated Power Output
[FP-7F] 13W x 2 [FP-4F] 12W x 2
Speakers
[FP-7F] (8cm x 12 cm) x 2 (with speaker box) [FP-4F] (8cm x 12 cm) x 2
Volume Level (SPL)
[FP-7F] 100 dB [FP-4F] 98 dB
* These figures were measured according to the method that is based on Roland’s technical standard.
Control
VOLUME, BALANCE, LCD CONTRAST [FP-7F o nly] MIC VOLUME, SPEAKER switch
Power Supply
DC 12 V (AC Adaptor)
Power Consumption
[FP-7F] 26 W [FP-4F] 24 W
Finish
Black, White
Dimensions
[FP-7F] 1,346 (W) x 375 (D) x 137 (H) mm / 53 x 14-13/16 x 5-7/16 inches
1,346 (W) x 397 (D) x 949 (H) mm / 53 x 15-11/16 x 37-3/8 inches (FP-7F with
dedicated stand KSC-44 and music rest)
[FP-4F] 1,342 (W) x 305 (D) x 135 (H) mm / 52-7/8 x 12-1/16 x 5-3/8 inches
1,342 (W) x 341 (D) x 940 (H) mm / 52-7/8 x 13-7/16 x 37-1/16 inches (FP-4F with
dedicated stand KSC-44 and music rest)
Weight
[FP-7F] 24.0 kg / 52 lbs 15 oz
36.6 kg / 80 lbs 12 oz (FP-7F with dedicated stand KSC-44 and music rest)
[FP-4F] 16.6 kg / 36 lbs 10 oz
29.1 kg / 64 lbs 3 oz (FP-4F with dedicated stand KSC-44 and music rest)
Accessories
Owner’s Manual, AC Adaptor, Power Cord (for AC Adaptor), Music Rest,
Damper Pedal (capable of continuous detection)
FP-7F shown with the optional stands (KSC-44-BK / KSC-44-WH / KS-18Z)
For additional pedals. FP-7F/FP-4F
package includes one DP-10.
FP-4F-BK with optional KSC-44-BK
FP-4F-WH with optional KSC-44-WH and RPU-3
FP-4F-BK with optional KS-18Z
Pro performance in a travel-friendly instrument
Play piano in any environment
Authentic piano sounds, natural keyboard touch, and functions to expand
your range of musical enjoyment are all packed into this compact keyboard.
Take this instrument anywhere, and enjoy your music in any environment,
from lessons to live performances.
