The HP ProLiant DL380p Gen8 sets the next generation standards of 2U 2-socket rack servers for the industry. With enhanced
configuration flexibility, unmatched performance, and leading energy efficient design the DL380p Gen8 offers the perfect solution for
the dynamic compute requirements of today's demanding datacenters.
Front View:
Rear View:
1.
Quick removal access panel
1.
PCIe 3.0 Slots 1, 2, 3-PCIe 2.0 top to bottom
2.
Second Intel Processor
2.
PCIe 3.0 Slots 4-6 top to bottom
3.
First Intel Processor
3.
Power supply 1
4.
24 DIMM slots: DDR3 Registered (RDIMM), Load Reduced
(LRDIMM), or Unbuffered (UDIMM) memory
4.
Power supply 1 Power LED
5.
Air Baffle
5.
Power supply 1 Power connection (with Intelligent PDU
communication)
6.
Hot-plug fans, full N+1 redundancy
6.
Power supply 2 Power connection (with Intelligent PDU
communication)
7.
Health LED
7.
Power supply 2 Power LED
8.
Power On /Standby button and system power LED button
8.
Power supply 2
9.
USB connector
9.
Unit ID LED/Button
10.
Unit ID LED
10.
USB connectors (4)
11.
Systems Insight Display
11.
Video connector
12.
Asset Tag
12.
iLO connector
13.
USB connector
13.
Serial connector
14.
Drive Bays
14.
FlexibleLOM ports (Shown: 4 ports 1Gb each /Optional: 2
ports 10Gb each)
15.
Optional Slim Optical Bay (SATA DVD-RW /ROM Optical Drive)
16.
Video connector
What's New
Secondary Riser for GPU support, and additional GPU options
New FlexibleLOM Adapters including the HP FlexFabric 10Gb 2-port 533FLR-T Adapter
New Smart Array P430 & P431 Controllers
96% Efficient Titanium Power Supply
3TB ioDrive2 IO Accelerator
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Overview
DA - 14212 North America — Version 54 — December 20, 2013
Page 1
