HP ProLiant ML310e Gen8, a single-socket 4U tower server, delivers essential availability and expansion needed to accommodate
changing business needs. It is ideal for remote sites and corporate branch offices running file/print, web messaging, and small vertical
applications or databases.
Front View:
Rear View:
1.
Quick removal access panel
1.
Power supply
2.
Power Supply
2.
Slot 4 PCIex16
3.
Four DIMM slots
3.
Slot 3 PCIex8
4.
System fan
4.
Slot 2 PCIex8
5.
Processor Heatsink
5.
Slot 1 PCIex4
6.
Four (4) PCIe expansion slots
6.
PCIe card bracket
7.
PCI Fan
7.
Serial Connector
8.
Half Height SATA DVD-ROM or DVD RW Optical Drive
8.
Video Connector
9.
Media Drive Blank
9.
UID LED Button
10.
Power Button
10.
iLO Dedicated Lan Port (optional)
11.
NIC Activity LED
11.
NIC Connector 1 (shared management)
12.
System Health
12.
NIC Connector 2
13.
UID LED button
13.
Four (4) USB Connectors
14.
Four (4) USB connectors
15.
Four (4) LFF or Eight (8) SFF SAS/SATA HDD cage
What's New
Updating supported options
QuickSpecs
HP ProLiant ML310e Generation 8 (Gen8)
Overview
DA - 14339 Canada — Version 28 — April 18, 2014
Page 1
