2. Technical Gas Data
a. Gas Specifications
* Measured at outlet sie of gas valve pressure tap when gas valve is on.
b. Gas Connections
Inlet connection -------------1/2-inch N.P.T.
Inlet supply size -------------1/2-inch N.P.T. (minimum)
Btu/hr input (per dryer) ----130,000 (32,760 kcal/hr)
1) Natural Gas
Regulation is controlled by the dryer's gas valve's internal regulator. Incoming supply pressure
must be consistent between a minimum of 6.0 inches and a maximum of 12.0 inches water column
(W.C.) pressure.
2) Liquid Propane (L.P.) Gas
Dryers made for use with L.P. gas have the gas valve's internal pressure regulator blocked open so
that the gas pressure must be regulated upstream of the dryer. The pressure measured at each
gas valve pressure tap must be a consistent 10.5 inches water column (W.C.). There is no
regulator or regulation provided in an L.P. dryer. The water column pressure must be regulated at
the source (L.P. tank) or an external regulator must be added to each dryer.
* Drill Material Size (D.M.S.) equivalents are as follows:
Natural Gas ..................... #25 = 0.1495” (3.7973 mm).
Liquid Propane Gas ........ #43 = 0.0890” (2.2606 mm).
TYPE OF GAS
Liquid Propane
(L.P.)
Conversion Kit
Part Number
MODEL
NUMBER
BTU
Per Hour
Rating
kcal/hr
Rating
Natural Liquid Propane (L.P.)
Qty. D.M.S.*
Part
Number
Qty. D.M.S.*
Part
Number
MDG-50 130,000 32,760 2 #25 140853 2 #43 140809 874044
TYPE OF GAS
NATURAL LIQUID PROPANE
Manifold Pressure* 3.5 inches W.C. 8.7 mb 10.5 inches W.C. 26.1 mb
In-Line Pressure 6.0 - 12.0 inches W.C. 14.92 - 29.9 mb 11.0 inches W.C. 27.4 mb
Shaded areas are stated in metric equivalents
