HP SignagePlayer mp8200 and mp8200s
HP SignagePlayer mp8200 and mp8200sHP SignagePlayer mp8200 and mp8200s
HP SignagePlayer mp8200 and mp8200s
1.
Optical DVD-ROM Drive
2.
Secure Digital (SD) Card Reader
3.
Rear I/O includes (6) USB 2.0 ports, DisplayPort v1.1a and VGA video interfaces, PS/2 mouse and keyboard ports, RJ-45
network interface, 3.5mm audio in/out jacks
4.
Front I/O includes (4) USB 2.0 ports, audio out , and a microphone/headphone jack
5.
100mm VESA mounting holes
6.
2.5" internal hard disk drive bay
7.
135W 87% efficient external Power Adapter or
180W 87% efficient external Power Adapter (when configured with discrete graphics)
8.
HP USDT Tower Stand (optional)
9.
HP Mouse (optional)
10.
HP Keyboard (optional)
QuickSpecs
HP SignagePlayer mp8200 Series
HP SignagePlayer mp8200 SeriesHP SignagePlayer mp8200 Series
HP SignagePlayer mp8200 Series
Overview
DA - 14115 North America — Version 2 — October 28, 2011
Page 1
