Copyright © 2012 by AAS Technology SD-12
www.AAS.com.tw R201211-V12
User Manual
SD/HD-SDI Video Extender over CAT5 / 6 Kit
HD-SDE-UTPK
This kit allows HD-SDI to be transmitted up to 50m / 160ft via CAT6 and 60m / 200ft via CAT6
cable in a point-to-point configuration. The SDI-UTP Extender supports transmission of up to
1.485 Gbps uncompressed, un-encrypted digital video (optionally including embedded Audio
and/or Time Code) within television facilities and between professional video equipment.
Applications: Video production, broadcasting, camcorder, studio-tostudio, post-production, live
events, medical imaging displays, mobile video, HD/SD routing, HD CCTV, and medical imaging.
Features ..
Up to 50m / 160ft via CAT5 cable
Up to 60m / 200ft via CAT6 cable
Supports SDI-SMPTE 259M-C (270Mbps);
HD-SDI-SMPTE 292M (1.485, 1.485 / 1.001 Gbps)
LED diagnostics: sync, SDI detect
5V~24V DC
HD-SDE-UTPT
SD-12a
HD-SDE-UTPR
SD-12b
Tx – Camera Side
RxDVR Side
