Maytag 27" SINGLE WALL OVEN Installation Instructions

Download Installation instructions of Maytag 27" SINGLE WALL OVEN Oven for Free or View it Online on All-Guides.com.

Maytag 27
1
Maytag 27
2
30" DOUBLE WALL OVEN
30" WALL OVEN UNDER COUNTER27" WALL OVEN UNDER COUNTER
27" DOUBLE WALL OVEN
30" SINGLE WALL OVEN
1
1 1/4" Dia Conduit Access Hole*
2 5/8" Plywood Floor (Must Support 142 lbs)
DIMENSIONS
in cm
27MIN 68.58
24 MIN 60.96
27 7/16
±1/16 69.69
23 1/2 MIN 59.69
25 1/2
±1/16 64.77
27 3/4 70.49
26 3/4 67.95
24 7/16 62.07
4 to 33 10.2 to 83.8
27" SINGLE WALL OVEN
A
B
C
D
E
F
G
H
I
5/8" Plywood Floor (Must Support 142 lbs)
1 1 1/4" Dia Conduit Access Hole*
2
DIMENSIONS
1
1 1/4" Dia Conduit Access Hole*
2
5/8" Plywood Floor (Must Support 250 lbs)
DIMENSIONS
in cm
27 MIN 68.58
24 MIN 60.96
49 5/8
±1/16 126.05
23 1/2 MIN 59.69
25 1/2
±1/16 64.77
49 15/16 126.84
26 3/4 67.95
24 7/16 62.07
4 to 12 10.2 to 30.5
A
B
C
D
E
F
G
H
I
5/8" Plywood Floor (Must Support 250 lbs)
1
1 1/4" Dia Conduit Access Hole*
2
DIMENSIONS
in cm
30 MIN 76.20
24 MIN 60.96
49 5/8
±1/16 126.05
23 1/2 MIN 59.69
28 3/16
±1/16 71.60
49 15/16 126.84
29 3/4 75.57
24 7/16 62.07
4 to 12 10.2 to 30.5
A
B
C
D
E
F
G
H
I
1
1 1/4" Dia Conduit Access Hole*
2
5/8" Plywood Floor (Must Support 142 lbs)
DIMENSIONS
in cm
25 63.50
24 MIN 60.96
27 7/16 ±1/16 69.69
23 1/2 MIN 59.69
25 1/2 ±1/16 64.77
27 3/4 70.49
26 3/4 67.95
24 7/16 62.07
36 91.44
1 1/2 3.81
A
B
C
D
E
F
G
H
I
J
1
1 1/4" Dia Conduit Access Hole*
2
5/8" Plywood Floor (Must Support 142 lbs)
in cm
25 63.50
24 MIN 60.96
27 7/16 ±1/16 69.69
23 1/2 MIN 59.69
28 3/16 71.60
27 3/4 70.49
29 3/4 75.57
24 7/16 62.07
36 91.44
1 1/2 3.81
A
B
C
D
E
F
G
H
I
J
DIMENSIONS
NOTE: * Hole must be cut as close to corner of cabinet as possible.
** See Dealer for approved cooktops.
in cm
30 MIN 76.20
24 MIN 60.96
27 7/16
±1/16 69.69
23 1/2 MIN 59.69
28 3/16
±1/16 71.60
27 3/4 70.49
29 3/4 75.57
24 7/16 62.07
4 to 33 10.2 to 83.8
A
B
C
D
E
F
G
H
I
NOTES
Z Do not block air intake slots along bottom of oven
Y Gas or electric cooktops may be installed over ovens. See
cooktop installation instructions for cutout size.
W Electrical connection for electric cooktop must be in adjacent ac
-
cessible location. Cooktop and wall oven must be on separate
120/240 or 120\208 volt 60 Hz AC circuits.
Built-In 27" & 30"
Electric Wall Ovens
INSTALLATION
INSTRUCTIONS
8101P306-60
(04-99-01)
* * COOKTOPS
SINGLE WALL OVEN
DOUBLE WALL OVEN
403 WEST FOURTH STREET, NORTH · NEWTON IA 50208
27" WALL OVEN 30" WALL OVEN
in cm in cm
K 4 Burner Gas 2 1/8 MIN 5.4 MIN 2 1/8 MIN 5.4 MIN
K Electric 3 1/8 MIN 7.9 MIN 3 1/8 MIN 7.9 MIN
K Induction 3 1/8 MIN 7.9 MIN 3 1/8 MIN 7.9 MIN
